Temperature Range

-40 to +60°c

Vibration

100m/s2 (10-500Hz). 10g

Impedance

50Ω,75Ω

Frequency Range

DC to 1GHZ

Working Voltage

170V r.m.s at sea level

Withstanding Voltage

500V r.m.s at sea level

Contact Resistance

Center contact

≤10m Ω

Outer contact

≤5m Ω

Insertion Loss

≤0.24dB(6GHz)

Insulation resistance

≥1000M Ω

Center Conductor Retention Force

≥0.2N

Voltage Standing Wave Ratio

Straight

≤ 1.20/6GHz

Right angle

≤ 1.30/6GHz

Durability(mating)

≥ 500cycles
