Crimp Type RP TNC Male Female Connector for Cable RG59
| Place of Origin: | Guangdong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
Features:
The Threaded Neil Concealment connector emerged in 1956 as an alternative to the bayonet coupling Mechanism of the BNC. Utilizing the same
Temperature Range
-55~+155℃
Vibration
100m/S2 (10-2000Hz) 15g
Impedance
50Ω
Frequency Range
DC - 11GHz
Working Voltage
500V r.m.s at sea level
Withstanding Voltage
1500V r.m.s at sea level
Contact Resistance
Center contact
≤10m Ω
Outer contact
≤2.5m Ω
Insertion Loss
≤0.24dB(6GHz)
Insulation resistance
≥5000M Ω
Center Conductor Retention Force
≥0.57N
Voltage Standing Wave Ratio
Straight
≤ 1.22/3GHz
Right angle
≤ 1.30/3GHz
Durability(mating)
≥500cycles
